End-Tow Trailing

About End-Tow Trailing

These frames are designed for farmers who need wide machines but have width constraints when shedding or moving. They feature a unique flexing frame design to be effective on contoured, undulating or melon hole country and offer two and three bar options.

The End Tow frame design is fitted with a floating hitch and features unique flexing sections throughout the length of the machine which not only flex up and down but also fore and aft so the frame is able to twist over the length of the machine. This unique feature means wider machines are able to be utilised in uneven ground conditions while still maintaining seeding accuracy.

This superior ground following ability allows an even seeding depth whilst giving constant press wheel pressure for a faster, more even crop germination. The flexing design also means that frame stress and fatigue is minimised for a longer lasting frame.

End Tow trailing frames are constructed of 100x100x9mm RHS with plated joints on both the top and underside of the frame to ensure maximum strength and durability. The proven frame design built with experience ensures no dead weight is carried with all cross members load carrying or supportive, this allows for some flexibility with row spacings and provides better access to row units for servicing. The frame lifts very high making for easy servicing and general inspection of the row units.

The BOSS range of End Tow frames are available in a variety of seeding widths (18 M – 36 M) & configurations.

Features

2 or 3 Bar designs available.

Unique flexing sectional frame.

All pivots are fitted with replaceable spherical ball pivots.

Hydraulically folding drawbar (Optional).

Stay cables.

Hydraulic saddles are used to carry all hoses.

Saddle provisions for air seeder hosing.

2 stage parking jack.

Laser cut identification on drawbar end for all hydraulic hoses.

Laser cut hydraulic hose keepers provided when unhitching machine.

All hydraulics hoses are protected with spiral wrap in rub prone areas.

Parking stands.

Optional toolbox, handwash tank and drawbar basket.

Australian designed, made and owned.
